Olivetti PR2 - PR2 VER Board Connector Signals

683311W
6-20
6.6.4.1 PR2VER BOARD CONNECTOR SIGNALS
1 MAC21
2 MAC20
3 MAC11
4 MAC10
5 MAPH2
6 MAPH1
7 PIU35
8 PIU35
9 GND
10 GND
1 VCC
2 DAWRM
3 DACOM
4 FAZMA
5 PMAGN
6 VERMA
7 RESE0
8 F2FDA
9 PIU12
10 GND
J3
(MAGNETIC UNIT MOTOR)
1 FTR1B
2 FTR1A
3 FTR2B
4 FTR2A
J5
(MAGNETIC HEAD)
1 WRI1
2 WRI0
3 GND
4 GND
5 LEO1
6 LEO0
J4
(MAGNETIC UNIT RESET PHOTO.)
1 VCC
2 VCC
3 LED1
4 FAZZ0
1 OUT1
2 GND
J6
(ADJUSTMENTS)
J1
(CONNECTION TO MAIN BOARD)
J2
(CONNECTION TO MAIN BOARD)
