88
Power Supply Unit Section 3-2
Unit Limits for Expansion
I/O Blocks
The current consumption limits for the CPU Block and Expansion I/O Block
are given in the following table. Be sure that current consumption of the con-
nected Units does not exceed the following limits.
Note 1. The CPU Block current consumption includes the CPU Unit, Communica-
tions Unit, Inner Boards, and I/O Control Unit.
2. The Expansion I/O Block current consumption includes I/O Interface Unit.
3. An Analog Power Supply Unit must be counted as a Unit, just like I/O or
Dedicated I/O Units.
4. The maximum current consumption will be 3.6 A if the CQM1-PA203 Pow-
er Supply Unit is used.
3-2-3 Unit Weights
CPU Units
Power Supply Units
Inner Boards
Communications Unit
Temperature Control Units CQM1-TC00@
CQM1-TC10@
220 mA
CQM1-TC20@
CQM1-TC30@
190 mA
CompoBus/S Units CQM1-SRM21 180 mA
DeviceNet Unit CQM1-DRT21 80 mA
I/O Control Units CQM1H-IC101 2 mA
I/O Interface Units CQM1H-II101 3 mA
Unit Model number Current consumption
(5 V DC)
Block Number of Units Maximum current consumption
CPU Block 5 max. 3.0 A max. (See note 1.) 5.0 A max. total
(See note 4.)
Expansion I/O
Block
11 max. 2.0 A max. (See note 2.)
Model number Weight
CQM1H-CPU11 500 g max.
CQM1H-CPU21 510 g max.
CQM1H-CPU51
CQM1H-CPU61
Model number Weight
CQM1-PA203 460 g max.
CQM1-PA206 560 g max.
CQM1-PA216
CQM1-PD026
Inner Board Model number Weight
Pulse I/O Board CQM1H-PLB21 90 g max.
Absolute Encoder Interface
Board
CQM1H-ABB21
High-speed Counter Board CQM1H-CTB21
Analog Setting Board CQM1H-AVB41 60 g max.
Analog I/O Board CQM1H-MAB42 100 g max.
Serial Communications
Board
CQM1H-SCB41 90 g max.
Unit Model number Weight
Controller Link Unit CQM1H-CLK21 170 g max.
