137
Operating Modes Section 5-2
5-2-3 Startup Mode
The operating mode that the CQM1H starts in when power is turned ON
depends on the following three factors: The setting of pin 7 on the DIP switch
on the front of the CPU Unit, the PC Setup, and whether or not a Program-
ming Console is connected. The startup mode for different combinations of
these factors is shown in the following table.
Note The startup mode will depend on the setting of pin 7 on the DIP switch and the
type of device connected, in the way shown in the following table:
Note The following table shows the relationship between the startup mode and con-
necting cable when a device other than a Programming Device is connected.
5-2-4 Operation without a Battery
Operation is still possible when there is no internal battery, or the internal bat-
tery has expired, by writing the required data (user program, PC Setup, etc.)
to a Memory Cassette. In this case, turn ON pin 2 on the DIP switch on the
front of the CPU Unit so that data stored in the Memory Cassette is trans-
ferred to the CPU Unit automatically at startup.
Note If the internal battery expires, the data in the CPU Unit (user program, set-
tings, etc.) will be lost when the power is turned OFF.
Consider the following precautions when operating with no internal battery or
with an expired battery.
• When the internal battery expires, data will be affected in the following
way.
PC Setup Operating mode
Word Bits Value
DM 6600 08 to 15 00 Hex (See note below.)
01 Hex Operating mode last used before power was turned
OFF
02 Hex Operating mode specified in bits 00 to 07
00 to 07 00 Hex PROGRAM mode
01 Hex MONITOR mode
02 Hex RUN mode
Connected device at
power ON
Pin 7 setting
OFF ON
Nothing connected PROGRAM mode RUN mode
Programming Console Determined by Program-
ming Console mode switch
PROGRAM mode
(Communications with Pro-
gramming Console not
possible.)
Device other than Pro-
gramming Console
PROGRAM mode
(Communications with con-
nected device not possi-
ble.)
Either PROGRAM mode or
RUN mode depending on
connecting cable. (See
note.)
Connecting cable Startup mode
CS1W-CN114 + CQM1-CIF01/02 PROGRAM mode
CS1W-CN118 + XW2Z-200/500S(-V) PROGRAM mode
CS1W-CN226/626 RUN mode
CS1W-CN118 + XW2Z-200/500S-CV RUN mode
