94
Programming Devices Section 3-6
Programming Console Connections
DIP Switch Settings When connecting a Programming Console to the peripheral port, turn OFF pin
7 on the DIP switch. When pin 7 is OFF, the setting of pin 5 and the PC Setup
settings are disabled as shown in the following table.
3-6-2 Support Software
The different types of Support Software that can be used with the CQM1H are
shown in the following table.
Note Functional limitations are shown in the following table.
Unit Port DIP switch Programming
Console
Cable
Length Model number
CPU Unit Built-in peripheral
port
Turn OFF pin 7. CQM1H-PRO01-E 2 m Cable included with
Programming
Console
CQM1-PRO01-E 2 m and 0.05 m Cable included with
Programming
Console and
CS1W-CN114
C200H-PRO27-E 2 m and 0.05 m C200H-CN222 and
CS1W-CN114
4 m and 0.05 m C200H-CN422 and
CS1W-CN114
2 m CS1W-CN224
6 m CS1W-CN624
DIP switch pin 5 DIP switch pin 7 PC Setup (DM 6650)
Disabled OFF Disabled
Name Model number Format Computer OS Serial
communicati
ons mode
Model Functional
limitations
CX-Programmer
V1.2 or higher
WS02-CXP@@-E CD-ROM IBM PC/AT
or compati-
ble
Microsoft
Windows
95 or 98
Peripheral bus
or Host Link
CQM1H No
SYSMAC-CPT WS01-CPTB1-E 3.5-inch
floppy
disks
(1.44 MB)
and
CD-ROM
Microsoft
Windows
V 3.1
Host Link CQM1-
CPU43
Ye s ( s e e
note)
SYSMAC
Support
Software (SSS)
C500-ZL3AT1-E 3.5-inch
floppy
disks
Microsoft
DOS
V 3.2 or
higher
Peripheral bus
or Host Link
CQM1
