System Configuration Section 1-2
1-2-9 I/O Units
Name Number
of
points
Specifications Connection
method
Model number Input words
allocated
from IR 001
Output words
allocated from
IR 100
DC Input
Units
8 12 to 24 V DC, independent
commons (1 point per
common, 8 circuits)
Terminal block CQM1-ID211 1 word ---
16 12 V DC (16 points per
common, 1circuit)
CQM1-ID111
24 V DC (16 points per
common, 1 circuit)
CQM1-ID212
32 12 V DC (32 points per
common)
Connector CQM1-ID112 2 words
24 V DC (32 points per
common)
CQM1-ID213
24 V DC (32 points per
common)
CQM1-ID214
AC Input
Units
8 100 to 120 V AC (8 points
per common)
Terminal block CQM1-IA121 1 word
200 to 240 V AC (8 points
per common)
CQM1-IA221
Contact
Output
Units
8 2 A at 250 V AC (cosφ =1.0)
2 A at 250 V AC (cosφ =0.4)
2 A at 24 V DC
(16 A per Unit),
independent commons
CQM1-OC221 --- 1 word
16 2 A at 250 V AC (cosφ =1.0)
2 A at 250 V AC (cosφ =0.4)
2 A at 24 V DC
(8 A per Unit)
CQM1-OC222
8 2 A at 250 V AC (cosφ =1.0)
2 A at 250 V AC (cosφ =0.4)
2 A at 24 V DC
(16 A per Unit),
independent commons
CQM1-OC224
Tra n si s to r
Output
Units
8 2 A at 24 V DC (5 A per Unit)
8 points per common
CQM1-OD211
16 50 mA/4.5 V DC to
300 mA/26.4 V DC
16 points per common
CQM1-OD212
32 16 mA/4.5 V DC to
100 mA/26.4 V DC
Connector CQM1-OD213 2 words
500 mA/24 V DC, PNP
output
CQM1-OD216
16 300 mA/24 V DC, PNP
output
Terminal block CQM1-OD214 1 word
8 1.0 A/24 V DC, PNP output
(4A per Unit), short-circuit
protection
CQM1-OD215
Tr i a c
Output
Units
8 0.4 A at 100 to 240 V AC,
4 points per common,
2 circuits
CQM1-OA221
6 0.4 A at 100 to 240 V AC CQM1-OA222
