92
Programming Devices Section 3-6
3-6 Programming Devices
There are two types of Programming Devices that can be used: Hand-held
Programming Consoles and Support Software that is run on a Windows com-
puter. Support Software is usually used to write the programs, and a Program-
ming Console is then used to change operating modes, edit programs, and
monitor a limited number of points.
The following Programming Devices can be used with the CQM1H.
• Programming Consoles
• Support Software
CX-Programmer V1.2 or higher (see note 1)
SYSMAC-CPT (see note 2)
SYSMAC Support Software (SSS) (see note 2)
Note 1. None of the CQM1H-series CPU Units can connect to CX-Programmer
V1.1 or lower.
2. Refer to Restrictions when Using Support Software under 3-6-2 Support
Software when using the SYSMAC-CPT or SYSMAC Support Software.
3-6-1 Programming Consoles
There are two Programming Consoles that can be used with the CQM1H: The
CQM1H-PRO01-E, CQM1-PRO01-E and C200H-PRO27-E. These Program-
ming Consoles are shown below.
CQM1H-PRO01-E Programming Console
LCD area
Mode switch
Operation keys
Peripheral port
