System Configuration Section 1-2
1-2-6 Memory Cassettes
Note The accuracy of the clock is affected by the ambient temperature, as shown in
the following table.
1-2-7 Power Supply Units
Model number Memory Capacity Clock (see
note)
Saveable data (saved together) Reading/
writing
User
programs
Data
memory
(read-only
areas, PC
Setup)
Expansion
instruction
information
CQM1H-ME16K Flash
memory
16 Kwords No Yes Yes Yes AR area:
Memory
Cassette ↔
CPU (com-
parison
available)
Automatic
transfer at
power ON:
Memory
Cassette →
CPU
CQM1H-ME16R Yes
CQM1H-ME08K EEPROM 8 Kwords No
CQM1H-ME08R Yes
CQM1H-ME04K 4 Kwords No
CQM1H-ME04R Yes
CQM1H-MP08K EPROM 8K/16
Kwords
(According
to switch
setting)
No Yes Yes Yes Read only:
Memory
Cassette →
CPU
CQM1H-MP08R Yes
Ambient temperature Accuracy by month
55°C –3 to 0 min
25°C ±1 min
0°C –2 to 0 min
Name Specifications Model number
Supply voltage Operating
voltage range
Output capacity Service power
supply
AC Power Supply
Units
100 to 240 V AC,
50/60 Hz (wide
range)
85 to 265 V AC 5 V DC: 3.6 A
(18 W)
None CQM1-PA203
5 V DC: 6 A
24 V DC: 0.5 A
(30 W total)
24 V DC: 0.5 A CQM1-PA206
100 or 230 V AC
(selectable),
50/60 Hz
5 V DC: 6 A
24 V DC: 0.5 A
(30 W total)
CQM1-PA216
DC Power Supply
Units
24 V DC 20 to 28 V DC 30 W
5 V DC: 6 A
None CQM1-PD026
