17
System Configuration Section 1-2
1-2-11 Accessories
DIN Track
Maintenance
Accessories
Inner Board Connectors
Cables for Connecting Pulse I/O Boards to OMRON Servo Drivers
Cable for Connecting
Absolute Encoder
Interface Boards to
OMRON Absolute
Encoders
Connectors for 32-point I/O Units
Name Specifications Model number
DIN Track Track length: 1 m PFP-100N
Track length: 50 cm PFP-50N
Track length: 1 m PFP-100N2
DIN Track Brackets Mounting brackets fastened on both
sides of the PC to prevent it from
sliding left or right. Two are provided
with the CPU Unit.
PFP-M
Name Model number
Backup Battery CPM2A-BAT01
End Cover CQM1H-TER01
Inner Board Name of
connector on
cable
Model number Remarks
High-speed
Counter Board,
Pulse I/O Board,
Absolute Encoder
Interface Board,
Analog I/O Board
Socket XM2D-1501 Standard
accessories for
each Board
Hood XM2S-1511
Inner Board Relay Cable Servo Relay Unit Cable Servo Driver
Pulse I/O Board
(pulse outputs)
XW2Z-@@@J-A3 XW2B-20J6-3B For U-series Servo Drivers:
XW2Z-@@@J-B1
R88D-UP@@@
For M-series Servo Drivers:
XW2Z-@@@J-B2
R88D-MT@@@
For H-series Servo Drivers:
XW2Z-@@@J-B3
R88D-H@@@
Inner Board Cable Compatible OMRON
Absolute Encoder
Absolute Encoder
Interface Board
E69-DC5 E6F-AG5C-C
E6CP-AG5C-C
E6C2-AG5C-C
I/O Unit Connector type Model number
(by Fujitsu)
Set model number
(from OMRON)
CQM1-ID112/213
(32 inputs)
CQM1-OD213
(32 outputs)
Soldered
(Standard accessory)
Socket FCN-361J040-AU C500-CE404
Connector cover FCN-360C040-J2
Crimped Housing FCN-363J040 C500-CE405
Contact FCN-363J-AU
Connector cover FCN-360C040-J2
Pressure welded FCN-367J040-AU C500-CE403
To Next Page
