Omron CQM1H - 08-2005 User Manual

16
System Configuration Section 1-2
Temperature Control
Units
2 thermocouple inputs (K/J), ON/OFF
or advanced PID control, transistor
(NPN) output, 2 loops
CQM1-TC001 1 or 2 words 1 or 2 words
2 thermocouple inputs (K/J), ON/OFF
or advanced PID control, transistor
(NPN) output, 2 loops
CQM1-TC002 1 or 2 words 1 or 2 words
2 platinum resistance thermometer
inputs (Pt, JPt), ON/OFF or advanced
PID control, transistor (NPN) output,
2 loops
CQM1-TC101 1 or 2 words 1 or 2 words
2 platinum resistance thermometer
inputs (Pt, JPt), ON/OFF or advanced
PID control, transistor (NPN) output,
2 loops
CQM1-TC102 1 or 2 words 1 or 2 words
2 thermocouple inputs (K/J/T/L/R/S/B),
ON/OFF or advanced PID control,
transistor (NPN) output, 4 loops
CQM1-TC201 1 word 1 word
4 thermocouple inputs (K/J/T/L/R/S/B),
ON/OFF or advanced PID control,
transistor (PNP) output, 4 loops
CQM1-TC202 1 word 1 word
4 platinum resistance thermometer
inputs (Pt, JPt), ON/OFF or advanced
PID control, transistor (NPN) output,
4 loops
CQM1-TC301 1 word 1 word
4 platinum resistance thermometer
inputs (Pt, JPt), ON/OFF or advanced
PID control, transistor (PNP) output,
4 loops
CQM1-TC302 1 word 1 word
2 thermocouple inputs (K/J/T/L/R/S/B),
ON/OFF or advanced PID control,
transistor (NPN) output, 2 loops, heater
burnout detection function
CQM1-TC203 1 word 1 word
2 thermocouple inputs (K/J/T/L/R/S/B),
ON/OFF or advanced PID control,
transistor (PNP) output, 2 loops, heater
burnout detection function
CQM1-TC204 1 word 1 word
2 platinum resistance thermometer
inputs (Pt, JPt), ON/OFF or advanced
PID control, transistor (NPN) output,
2 loops, heater burnout detection
function
CQM1-TC303 1 word 1 word
2 platinum resistance thermometer
inputs (Pt, JPt), ON/OFF or advanced
PID control, transistor (PNP) output,
2 loops, heater burnout detection
function
CQM1-TC304 1 word 1 word
Linear Sensor Interface
Units
Measure voltage or current inputs from
linear sensors and convert the
measurements to numeric data for
comparative decision processing.
Standard type
CQM1-LSE01 1 word 1 word
With monitor output
(–9.999 V to 9.999 V).
CQM1-LSE02 1 word 1 word
CompoBus/S Master Unit 128 points (64 inputs and 64 outputs),
64 points (32 inputs and 32 outputs), or
32 points (16 inputs and 16 outputs)
selectable with a switch.
CQM1-SRM21-V1 1, 2, or
4words
1, 2, or 4 words
DeviceNet I/O Link Unit DeviceNet Slave: 32 points
(16 inputs and 16 outputs)
CQM1-DRT21 1 word 1 word
Name Specifications Model number Input words
allocated
from IR 001
Output words
allocated from
IR 100
