Omron CQM1H - 08-2005 User Manual

53
Input Unit Specifications Section 2-2
2-2-2 DC Input Units
Item CQM1-ID211 CQM1-ID212
Name 12 to 24-V DC 8-point Input Unit 24-V DC 16-point Input Unit
Input Voltage
12 to 24 V DC
+10%
/
–15%
24 V DC
+10%
/
–15%
Input Impedance 2.4 kΩ 3.9 kΩ
Input Current 10 mA typical (at 24 V DC) 6 mA typical (at 24 V DC)
ON Voltage 10.2 V DC min. 14.4 V DC min.
OFF Voltage 3.0 V DC max. 5.0 V DC max.
ON Delay Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
OFF Delay Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
Default: 8 ms max. (can be set between 1 and
128 ms in PC Setup, see note)
No. of Inputs 8 points (independent commons) 16 points (16 points/common, 1 circuit)
Internal Current
Consumption
50 mA max. at 5 V DC 85 mA max. at 5 V DC
Weight 180 grams max. 180 grams max.
Circuit
Configuration
Terminal
Connections
COM0
IN0
COM7
IN7
2.2 kΩ
Input
LED
Internal
Circuits
560 Ω
Note The input power supply polarity may be
connected in either direction.
Input
LED
Internal
Circuits
2.2 kΩ
560 Ω
IN0
to
IN15
COM
3.9 kΩ
Input
LED
Internal
Circuits
560 Ω
Note The input power supply polarity may be
connected in either direction.
B0
IN0
A0
B1
COM0
A1
B2
IN1
A2
B3
IN3
A3
B4
IN4
A4
B5
IN5
A5
B6
IN6
A6
B7
IN7
A7
B8
A8
COM1
IN2
COM2
COM3
COM4
COM5
COM6
COM7
NC
NC
–
+
+
–
–
–
–
–
–
–
+
+
+
+
+
+
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
B0
IN1
IN1
A0
B1
IN2
IN3
A1
B2
IN4
IN5
A2
B3
IN6
IN7
A3
B4
IN8
IN9
A4
B5
IN10
IN11
A5
B6
IN12
IN13
A6
B7
IN14
IN15
A7
B8
COM
A8
COM
–
–
