210
Pulse I/O Board Section 8-2
Example Configurations Using OMRON Servo Driver Cables
Pulse I/O Board
Relay Cable
Servo Relay Unit
U-series Connecting
Cable
M-series Connecting
Cable
H-series Connecting
Cable
U-series M-series H-series
Cable for connecting
to Servo Driver
Servo Driver
XW2Z- ((( J-A3
XW2B-20J6-3
XW2Z- ((( J-B1 XW2Z- ((( J-B3 XW2Z- ((( J-B2
R88D-UP ((( R88D-MT ((( R88D-H (((
