34
Functions Listed by Purpose Section 1-4
Detection sensor
input
Reducing wiring and
space required for
sensor output
Sensor Unit Input function for
Optic Fiber
Photoelectric
Module,
Photoelectric
Module with
Separate
Amplifier and
Proximity Module
with Separate
Amplifier
(amplifier function)
Up to four Sensor Modules
(amplifier sections) of three kinds
of sensor (fiber photoelectric
sensor, photoelectric sensor with
separable amplifier and proximity
sensor with separable amplifier)
can be mounted to a single
Sensor Unit. Sensor Modules can
be selected and combined
according to the object to be
detected and the distance.
Analog sensor input Reading analog voltage
or current signals from
sensors or measuring
devices, and outputting
analog signals to
inverters or analog
control devices
Analog Input Unit
or Analog
Output Unit
(Power Supply
Unit required)
Analog I/O Analog input: 4 points (0 to
20 mA, 0 to 5 V, –10 to +10 V)
Analog output: 2 points (0 to
20 mA, –10 to +10 V)
Reading distance data
such as level
differences and panel
thicknesses, by using in
combination with
displacement sensors
Linear Sensor
Interface Unit
Input/operation
function for data
from linear sensor/
amplifier
High-speed, high-precision
measurement of voltage or
current input from linear
(displacement) sensors is
performed and the
measurements are converted to
numeric data for comparative
decision processing. Input can be
held according to external timing
signals.
Sampling cycle: 1 ms; External
timing sampling time: 0.3 ms
Temperature
control functions
Reading data from two
temperature controllers
with one Unit
Temperature
Controller Unit
CQM1-TC00@
CQM1-TC10@
Temperature
control function
Number of loops: 2
Input: Thermocouple (K, J) or
platinum resistance thermometer
(Pt, JPt)
Output: ON/OFF or advanced PID
control (time-proportional) control
Reading data from two
or four temperature
controllers with one Unit
Temperature
Controller Unit
CQM1-TC20@
CQM1-TC30@
Number of loops: 4 or 2 (heater
burnout detection function)
Input: Thermocouple (K, J, L, T,
R, S, B) or platinum resistance
thermometer (Pt, JPt)
Output: ON/OFF or advanced PID
control (time-proportional) control
Purpose Unit/Board Function Details
