37
CQM1-CQM1H Comparison Section 1-5
Note When considering the restrictions on the number of connectable Units, an
Analog Power Supply Unit must be counted as a Unit, just like I/O or Dedi-
cated I/O Units.
Instruction execution
times
LD instruction: 0.375 µs
MOV instruction: 17.6 µs
LD instruction: 0.5 µs
MOV instruction: 23.5 µs
Overseeing time 0.70 ms 0.80 ms
CPU Unit built-in input
points
16 points
Maximum number of
Units (see note)
The number of I/O Units and Dedicated I/O
Units that can be connected to a CQM1H
CPU Unit is as follows:
CPU Block only: 11 Units max.
CPU Block and Expansion I/O Block
CPU Block: 5 Units max.
Expansion I/O Block: 11 Units max.
The number of I/O Units and Dedicated I/O
Units that can be connected to a CQM1 CPU
Units is as follows:
CQM1-CPU11/21-EV1: 7 Units max.
(I/O Units only)
CQM1-CPU41/42/43/44-EV1: 11 Units max.
(I/O Units or Dedicated I/O Units)
Inner Boards CQM1H-CPU51/61: 2 slots None
High-speed counters Supported if CQM1H-CTB41 High-speed
Counter Board is mounted.
Not supported
Item CQM1H CQM1
Pulse I/O Supported if CQM1H-PLB2 Pulse I/O Board 1
is mounted.
Supported for CQM1-CPU43-EV1 CPU Unit.
Absolute encoder
interface
Supported if CQM1H-ABB21 Absolute
Encoder Interface Board is mounted.
Supported for CQM1-CPU44-EV1 CPU Unit.
Analog settings Supported if CQM1H-AVB41 Analog Setting
Board is mounted.
Supported for CQM1-CPU42-EV1 CPU Unit.
Analog I/O Supported if CQM1H-MAB42 Analog I/O
Board is mounted.
Supported for CQM1-CPU45-EV1 CPU Unit.
Protocol macros Supported if CQM1H-SCB41 Serial
Communications Board is mounted.
Not supported
Communications Units CQM1H-CPU51/61: 1 Unit None
Controller Link Supported if CQM1H-CLK21 Controller Link
Unit is connected.
Not supported
Peripheral
port con-
nections
Connect-
ing cable
for per-
sonal com-
puter
CS1W-CN@@@
Note Connection to personal computer also
possible with CQM1-CIF01/02 via
CS1W-CN114 Conversion Cable.
CQM1-CIF01/02
Connect-
ing cable
for Pro-
gramming
Console
CQM1-PRO01 Programming Console: Use the
cable provided with the Console or CS1W-
CN114.
C200H-PRO27 Programming Console: CS1W-
CN224/624
Note Connection to Programming Console
also possible with C200H-CN222/422 via
CS1W-CN114 Conversion Cable.
CQM1-PRO01 Programming Console: Use
the cable provided with the Console.
C200H-PRO27 Programming Console:
C200H-CN222/422
Item CQM1H CQM1
