Omron CQM1H - 08-2005 User Manual

40
CQM1-CQM1H Comparison Section 1-5
New instructions TTIM (TOTALIZING TIMER) instruction,
SEND(90)/RECV(98)/CMND(––) (network
communications) instructions, PMCR
(PROTOCOL MACRO) instruction,
STUP(––) (CHANGE RS-232C SETUP)
instruction and 19 floating-point math
instructions available.
The instructions on the left are not supported
by the CQM1.
Serial communications
ports
One built-in peripheral port
Supports the following communications: Peripheral bus, Programming Console bus, Host Link,
no-protocol
One built-in RS-
232C port
CQM1H-CPU61/51/21:
Supports Host Link,
no-protocol, NT Link (1:1
mode) and 1:1 Data Link
communications.
CQM1H-CPU11: None
Note Programming Con-
sole functions support-
ed from a PT (except
when pin 7 on the DIP
switch is OFF).
One built-in
RS-232C port
Supports Host Link and
no-protocol
communications (except
CQM1-CPU11/21-EV1).
CQM1-CPU4@-EV1 also
supports 1:1 Data Link, NT
Link (1:1 mode)
Note CQM1-CPU4@-EV1
supports Program-
ming Console func-
tions from a PT.
Serial Commu-
nications Board
(available sepa-
rately): 1 RS-
232C port and
1 RS-422A/485
port
Host Link, no-protocol, 1:1
Data Link, NT Link (1:1
mode, 1:N mode) and proto-
col macro communications
supported.
None ---
Serial communications
modes
No-protocol
Up to 256 bytes can be sent or received with special instruction. Header codes and end codes
can be set. Transmission delay time setting available.
Host Link
All of the CPU Unit’s I/O memory areas, and the user’s program can be accessed using Host
Link commands.
NT Link
(1:1 mode, 1:N
mode)
Data transfer is possible
without program between the
PC and an OMRON PT. The
ratio of PCs to PTs can be
one-to-one or
one-to-many.
The 1:N-mode NT Link
connections are possible
only for the RS-232C port or
RS-422A/485 port on the
Serial Communications
Board.
NT Link
(1:1 mode
only)
CQM1-CPU4@-EV1 only
Protocol macro Protocol macro communica-
tions supported using the
RS-232C port or RS-422A/
485 port on the Serial Com-
munications Board (CQM1H-
CPU51/61 only).
Sending and receiving data
is possible using one
instruction via a user-defined
protocol from the ladder
program.
Not supported ---
Power failure detection
time
AC power supply: 10 to 25 ms
DC power supply: 5 to 25 ms
Standard accessories Battery Set: CPM2A-BAT01 Battery Set: C500-BAT08
Item CQM1H CQM1

Omron CQM1H - 08-2005 Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Omron
Program Capacity	3.2K steps
Model	CQM1H
I/O Points	512 points max
