Omron CQM1H - 08-2005 User Manual

72
Output Unit Specifications Section 2-3
Note If the output current of any output exceeds the detection current, the output
will be turned OFF. At the same time, the alarm output (ALM) will turn ON
(Low).
If an alarm output turns ON, eliminate the problem that caused the detection
current to be exceeded. The internal temperature of the element will drop and
the alarm will automatically be cleared.
Terminal Connections
Item CQM1-OD216
The COM terminals and 0-V outputs
are internally connected, but they all
must be wired.
Note Do not reverse the polarity of
the load power supply. If the
load power supply is con-
nected incorrectly, the loads
may not operate correctly.
4 4
5 5
6 6
7 7
8 8
9 9
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
3 3
2 2
19 19
20 20
1 1
OUT0
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
0V
0V
OUT0
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
10 10
0V
ALM
AB
++
24 V DC24 V DC
+
24 V DC
+
24 V DC
Wd m Wd (m+1)
–
COM
COM
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
COM
COM
–
–
–
