Specifications and Dimensions
178
FQ-CR2 User’s Manual
• AC Adapter
Dimensions
• I/O Cables
FQ-WD002
Item Model FQ-AC1 FQ-AC2 FQ-AC3 FQ-AC4 FQ-AC5 FQ-AC6
Plug type AAACBFO
Certified standards PSE UL/CSA CCC mark --- --- ---
Input voltage 100 to 240 VAC (90 to 264 VAC)
Input current 0.4 A max., 100 VAC, 50 Hz when connected to maximum load
Input frequency 47 to 63 Hz
Output voltage 15 VDC±5%
Output current 1 A max.
Ambient temperature range Operating: 0 to 40°C
Storage: −20 to 65°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 80% (with no condensation)
Material Case: PPE
Cable length 1.5 m
Dimensions 78 × 50 × 30 mm (without power cable)
Weight Approx. 270 g
Contents of label on AC
Adapter
(100)
L
*1
(15.5 dia.)
6.4 dia.
(39.8)
(5)
35
19.5 dia.
*1: The cable length is given in the following table.
Model L
FQ-WD002 2 m
(Unit: mm)
FQ Sensor User Manual.book 178 ページ ２０１１年７月８日 金曜日 午後２時３０分
