Logging Measurement Data and Image Data
FQ-CR2 User’s Manual
77
7
Convenient Functions
Starting and Stopping Logging
After logging is started (i.e., set to ON), the specified image data and measurement data will be saved in the
SD card or computer hard disk each time measurements are performed.
(Run Mode)
1 Press [Logging].
2 Press [Image logging] or [Data logging].
3 Press [ON] to start logging.
Press [OFF] to stop logging.
4 Press [Back].
Saved Log Data
• Storage Locations and File Names for Logged File Data
*1: A five-digit number is assigned as a name to the image data storage folder in the order of folder creation as
shown below.
Up to 100 images are stored in each folder.
00000
00001
:
:
*2: Files are stored in the following folder when the PC Tool is used.
\My Documents\OMRON FQ\ SDCard
• File format
Image logging: Image data is saved in a special format for OMRON Sensors. (The file name extension is IFZ.)
Data logging: Measurement data is saved in the following CSV format.
*1: The date is given in the following format: 2010/6/1 (for June 1, 2010). The time is given in the following format: 12:01:20 (for 12:01 and 20 sec-
onds pm).
Item Description
Image logging • All: All images will be logged regardless of the measurement results.
• Only NG: Only images for which the overall judgement was NG will be logged.
• None: No images will be logged (default).
Data logging • All: All measurement data (Measured values) will be logged regardless of the measurement results.
• Only NG: Only measurement data (Measured values) for which the overall judgement was NG will
be logged.
• None: No measurement data (Measured values) will be logged (default).
The logging parameter settings are the same for file logging and recent results logging.
Data Storage location File name
Image logging \sensor_name\
LOGIMAGE\number
*1, *2
YYYY_MM_DD-HH_MM_SS.IFZ
Example: The following name would be used for measurements performed at
10:10:21 pm on March 10, 2010.
2010_03_10-22_10_21.IFZ
Data logging \sensor_name\LOGDATA
*2
YYYY_MM_DD-HH_MM_SS.CSV
Example: The following name would be used for measurements performed at
10:10:21 pm on March 10, 2010.
2010_03_10-22_10_21.CSV
Note
<Date*1>,<Time*1>,<Measurement value for inspection item 0>,<Measurement value for inspection item 1>,...,<Measurement value for inspection item 31>,Delimiter
Field separator
Record separator
