Precautions for Correct Use
• A restart is required after configuring the Ethernet, EtherNet/IP, and EtherCAT settings.
•
When multi-line random-trigger mode is selected, the communication settings needs to be
configured for each line.
However, the RS-232C/422 settings are common between the lines.
For the other communication settings, individually configure the settings in the system set-
tings for each line.
5 Designing Exchange with External Devices
5 - 4
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
