(4) Security settings data
Refer to 8-7 Using the Security Setting T
ool on page 8 - 10.
Precautions for Correct Use
If the FH/FHV sensor is in the Multi-line Random-trigger Mode, the settings data for the FH/FHV
sensor must be saved for each individual line.
Procedures for transferring the data from the Sysmac Studio to the NJ/NX/NY-series Control-
ler (Sysmac Studio to NJ/NX/NY
-series Controller)
Establish an online connection with the NJ/NX/NY-series Controller to transfer the data from
the Sysmac Studio to the NJ/NX/NY-series Controller.
Refer to Sysmac Studio Version 1 Operation Manual (Cat. No. W504).
(1) Establish an online connection between the NJ/NX/NY-series Controller and the comput-
er that runs the Sysmac Studio.
(2) Select Synchronize from the Controller Menu.
(3) Select Transfer to Sensor.
Procedures for transferring the data from the external memory to the FH/FHV sensor (exter-
nal memory to FH/FHV sensor)
Use the external memory that holds the settings data to load the data to the FH/FHV sensor.
Refer to 2-8-2 Saving and Loading the Settings Data for the FH/FHV Sensor Controller on
page 2 - 45.
2-8-4
Transferring Data to the Sysmac Studio
This section describes the how to transfer the data in the NJ/NX/NY-series Controller and the FH/FHV
sensor to the Sysmac Studio when synchronizing the Sysmac Studio and the FH/FHV sensor
.
This section describes the procedures for transferring data from the Sysmac Studio via the external
memory.
Use the following procedures to synchronize the data from the Sysmac Studio.
1 Save the settings data for the FH/FHV sensor in the FH/FHV sensor from to the external mem-
ory
.
2 Establish an online connection with the NJ/NX/NY-series Controller and transfer the data from
the NJ/NX/NY
-series Controller to the Sysmac Studio.
3 Use the external memory that holds the data saved in Step 1 to load the data to the Sysmac
Studio.
4 Save the Sysmac Studio project.
2 Basic Operations
2 - 47
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
2-8 Precautions on Synchronization through
an NJ/NX/NY-series Controller
2
2-8-4 Transferring Data to the Sysmac Studio
