Item Description
Scene Name Displays the scene name. (Maximum of 15 characters)
Author Displays the author name. (Maximum of 15 characters)
Comment Displays the comment. (Maximum of 255 characters)
Each item in the list can be directly edited.
2-5-4
Searching for a Scene
You can search for a scene in the list by entering any scene name in the search box and then clicking
the search button (
). Clicking the search clear button ( ) clears the search results.
2-5-5
Switching Scene Groups
Clicking the scene group editing button displays the scene group editing window.
Y
ou can switch scene groups by selecting the target scene group in the list and then clicking the
Switch button.
When scene switching is performed, the scene data editing screen is closed automatically if it is open
in the Edit Pane.
2-5-6
Managing Scene Groups
Right-clicking a target scene group in the scene group list in the scene group editing window displays
the following menu.
2 Basic Operations
2 - 33
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
2-5 Basic Operations of Scene Data
2
2-5-4 Searching for a Scene
