6-2
Checking Measurement Results
You can check the measurement results in each editing screen.
On the displayed image, the measurement results of the selected processing unit are displayed as a
graphic.
6-2-1
Checking Detailed Results
Scene maintenance window, monitor window, and scene data edit-
ing screen
Open the Flow item and Detail result item and click the Measure button.
If you select any of the processing units in the list of the Flow item, the measurement result of each
item that is a judgment result of that processing unit will be displayed in the Detail result item.
<Scene maintenance screen>
<Monitor window>
<Scene data editing screen>
6 Online Debugging
6 - 4
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
