Setting Procedure
You can open the system settings screen by double-clicking System data in the Multiview Explorer or
by right-clicking it and selecting Edit from the menu.
In the system settings screen, you can click any of the following buttons to configure the correspond-
ing settings.
For details, refer to V
ision System FH/FHV Series User's Manual (Cat. No. Z365).
Button Setting Item Description
Parallel I/O Sets the Parallel I/O settings.
RS-232C/422 Sets the RS-232C/422 settings.
Ethernet Sets the settings related to Ethernet.
EtherNet/IP Sets the settings related to EtherNet/IP.
EtherCAT Sets the settings related to EtherCAT.
PROFINET Sets the settings related to PROFINET.
