8-9
Using the Image File Save Tool
With this tool, it is possible to save the copy of both logged images and image files that are saved in
the Image Sensor to a RAM disk or external memory device in FH/FHV vision sensor, or to a comput-
er. The save image file format can be selected from “Bitmap” or “Jpeg”.
8-9-1
Opening the Image File Save Tool
Double-click on Tool - Image file save in the Multiview Explorer, or by right-clicking it and selecting
Edit from the menu.
The image file save tool window is displayed in the Edit Pane.
8-9-2
Saving the Image File
The image files in the following media can be copied, and then saved in the same media or computer
as bitmap or JPEG.
• RAMDisk of FH/FHV vision sensor
• Connected external memory to FH/FHV vision sensor
If the file is saved in the JPEG format, it is possible to specify the quality (compression ratio) for each
file.
1 Select Image files for T
arget data.
2 Select the file.
You can select data on a folder basis or on a file basis.
3 Select the save destination folder.
T
o save the file by copying it to the external memory of the FH/FHV vision sensor, select
Sensor.
To save the file to the computer, select Computer.
If you wish to delete the original file after saving, select the Delete original data after save
check box.
4 Save the file.
Click the Save file button to save the file.
The selected file(s) are saved as the specified format.
8 Other Useful Functions
8 - 12
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
