Group Item
Region setting Sets the region for performing correction.
Output image Selects the image to output.
4-1-4
Support Measurement
This is a processing unit for providing support for calculation processing, data acquisition and brows-
ing, and other processing.
The main setting items are as follows.
Group Item
Setting
*1
Sets the condition for performing measurement.
Judgment condition Sets the judgment condition for measurement values.
Output conditions Sets the reflection condition for the coordinates or overall judgment output as
measurement results.
*1. The item names differ for each processing unit.
Precautions for Correct Use
The decimal point symbol in the editing screen for Unit macros and Unit calculation macro proc-
essing items is fixed at "." (period), regardless of your computer's OS settings.
4-1-5
Branch
This is the processing unit for performing branching processing.
The main setting items are as follows.
Group Item
Branch setting Sets the condition for performing branching.
Setting Sets the communication function and timeout function for performing flow con-
trol by communication.
Output conditions Sets the reflection condition for the overall judgment.
4-1-6
Output Result
This is the processing unit for outputting measurement results to an external device.
The main setting items are as follows.
Group Item
Setting Sets the content to output.
Output format Sets the format of the data to output.
Output conditions Sets the reflection condition for the overall judgment.
4-1-7
Display Result
This is the processing unit for displaying any text, figure, or image on the screen displaying the meas-
urement results.
The main setting items are as follows.
