Basic Design Flow 1
This section describes the flow for designing a system that uses NJ/NX/NY-series CPU Unit as a con-
troller.
For details on the program on the NJ/NX/NY-series CPU Unit side, task design, and debugging, refer
to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504).
Precautions for Correct Use
The settings data for the FH/FHV sensor cannot be synchronized with the data in the Sysmac
Studio project via an NJ/NX/NY-series Controller.
For details, refer to 2-8 Precautions on Synchronization through an NJ/NX/NY-series Controller
on page 2 - 44.
To synchronize them, directly connect the FH/FHV sensor to the computer that runs Sysmac
Studio via Ethernet.
For details, refer to 3-4 Synchronizing Project Data and Sensor Setting Data on page 3 - 7.
New project settings
Create a project file.
(1) Starting Sysmac Studio
Start Sysmac Studio.
For details, refer to Starting and Exiting the Sysmac Studio in the Sysmac Studio Version 1
Operation Manual (Cat. No. W504).
(2) Designing a new project
Create a new project.
For details, refer to Creating a Project File in the Sysmac Studio Version 1 Operation Manual
(Cat. No. W504).
Controller configuration and settings
• Controller configuration:
(1)
Creating an EtherCAT configuration
Register FH/FHV as an EtherCAT slave in EtherCAT.
For details, refer to EtherCAT Configuration and Settings in the Sysmac Studio Version 1
Operation Manual (Cat. No. W504).
(2)
Registering device variables
When using or using after editing device variables for the user defined variables to connect the
FH/FHV I/O information and program, register the device variables in I/O Map.
For details, refer to Creating Device Variables in the Sysmac Studio Version 1 Operation
Manual (Cat. No. W504).
• Controller settings:
(1)
Editing slave parameters
Edit the Operation Settings of the slaves.
For details, refer to Creating the EtherCAT Slave Terminal Configuration in the Sysmac Studio
Version 1 Operation Manual (Cat. No. W504).
2 Basic Operations
2 - 3
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
2-1 Basic Design Flow 1
