Using the Conveyor Panorama Dis-
play tool
This tool is used for conveyor tracking applications.
This tool is used to display a panoramic composition of workpieces being carried by conveyor. To ad-
just the trigger interval and conveyor speed for additional lines or new product types, this tool com-
bines images to create a panoramic image, and then displays the region of captured image and the
registered region of the model of the target objects over it.
For details, refer to Vision Sensor FH series Conveyor Tracking Application Programming Guide (Cat.
No. Z368).
