3-3
Establishing an Online Connection
with a V
ision Sensor
Connect with FH/FHV vision sensor on the network.
3-3-1
Establishing an Online Connection from the Sensor Connection
Screen
You can open the sensor connection screen in the Edit Pane by double-clicking the type name of the
FH/FHV vision sensor in the Multiview Explorer or by right-clicking it and selecting Edit from the menu.
<Multiview Explorer>
<Sensor connection screen>
Click the Search for sensors button of Online - Sensor connection to display a list of the IP ad-
dresses of the FH/FHV vision sensors on the same network. Select the FH/FHV vision sensor you
wish to connect to and then click the Connect button.
Y
ou can also directly enter an IP address in the IP address field.
If you wish to connect with an FH/FHV vision sensor via a router, directly enter the IP address and
then click the Connect button.
3 Connecting with a Vision Sensor
3 - 4
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
