Classification Item
Sysmac
Studio
FH
Project management Data management for a single FH vision sensor Yes Yes
Data management for all devices Yes No
Screen customization and screen layout control No Yes
Creating and displaying dedicated dialog boxes No Yes
Tools Communication Command Macro Yes Yes
Save file Yes Yes
Calibration Support Tool Yes Yes
NG analyzer No Yes
User Data Yes Yes
Security settings Yes Yes
Downloading and uploading setting values No Yes
Image file save Yes Yes
Registered image
Manager
Yes Yes
Flow viewer No Yes
Update standard position tool Yes Yes
Conversion scene group data tool Edit Yes Yes
Scene Group Saving Destination Settings Yes Yes
Scene Control macro tool Yes Yes
Custom dialog tool No Yes
Custom dialog No Yes
Configuration Copy No Yes
Line Maintenance No Yes
Conveyor Panorama Display
Yes
*1
No
Conveyor Calibration Wizard
Yes
*1
No
Calibration Plate Print
Yes
*1
No
Simulation Single simulation Yes Yes
Integrated simulation Yes No
*1. For details, refer to V
ision Sensor FH series Conveyor Tracking Application Programming Guide (Cat. No.
Z368).
2-7-3
Comparison with FHV Series Unit Functions
The following table shows the main differences between the functions provided with an FHV series de-
vice and the FHV tool.
Y
es: Supported, No: Not supported
Classification Item
Sysmac
Studio
FHV
FHV
Simula-
tor
Project management Data management for a single FHV vision sensor Yes Yes Yes
Data management for all devices Yes No No
Screen customization and screen layout control No Yes Yes
Creating and displaying dedicated dialog boxes No Yes Yes
2 Basic Operations
2 - 42
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
