Overview of Processing Units
This section provides an overview of the processing units that can be edited in the FH/FHV tools.
For details on each of the processing units, refer to Vision System FH/FHV Series Processing Item
Function Reference Manual (Cat. No. Z341).
4-1-1
Input Image
This is a processing unit for loading images from a camera.
The main setting items are as follows.
Group Item
Camera setting Sets the camera shooting conditions.
Screen adjust Sets the conditions related to the lighting and lens.
White balance Sets the white balance in images loaded from the camera to correct its color
and to make the white parts appear as white.
Calibration Configures the settings for converting measurement results to the actual di-
mensions.
HDR setting Sets the method for combining images in order to obtain it with a wide dynamic
range.
Bright adjust setting Sets how much the brightness of loaded images to be adjusted.
4-1-2
Measurement
This is a processing unit for inspection and measurement.
The main setting items are as follows.
Group Item
Model Allows you to register the parts you wish to inspect as models.
Region setting Sets the range for searching a model and the range for calculating the amount
of a certain feature.
Detection point Sets which parts of a model you wish to detect as the coordinates during
measurement.
Ref. setting Changes the measurement values that will be the reference registered during
model registration and region setting.
Measurement condition Sets the condition for performing measurement.
Judgment condition Sets the judgment condition for measurement values.
Output conditions Sets the reflection condition for the coordinates or overall judgment output as
measurement results.
Color Sets the color information used for measurement.
4-1-3
Compensate Image
This is a processing unit for correcting images.
The main setting items are as follows.
Group Item
Filter setting Sets the filter conditions for image correction.
4 Configuring Measurement Settings
4 - 2
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
