Omron SYSMAC FH Series

To Next Page

To Previous Page

8-6

Help

You can display the FH/FHV tool manual.

Display the sensor connection screen in the Edit Pane by double-clicking the type in the Multiview Ex-

plorer or by right-clicking it and selecting Edit from the menu.

Click Sensor Information - Help to display the manual for the FH/FHV series vision sensors.

8 Other Useful Functions

8 - 9

FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
