Tree View Items Menu Item Description

Calibration

Support T

ool

Edit Displays the calibration support tool in the Edit Pane.

User Data Edit Displays the user data tool in the Edit Pane.

Save file Edit Displays the file saving tool in the Edit Pane.

Conveyor

Panorama

Display

Edit Displays the Conveyor Panorama Display tool in the

Edit Pane.

Image file

save

Edit Displays the image file save tool in the Edit Pane.

Scene Control

macro tool

Edit Displays the scene macro tool in the Edit Pane.

Conveyor Cali-

bration Wizard

Edit Displays the Conveyor Calibration Wizard tool in the

Edit Pane.

Scene Group

Saving Desti-

nation Set-

tings

Edit Displays the setting tool for the scene group saving

destination in the Edit Pane.

Calibration

Plate Print

Edit Displays the Calibration Plate Print tool in the Edit

Pane.

Security set-

tings

Edit Displays the security setting tool in the Edit Pane.

Registered im-

age

Manager

Edit Displays the registered image manager in the Edit

Pane.

Update stand-

ard position

tool

Edit Displays the update standard position tool in the Edit

Pane.

Conversion

scene group

data tool Edit

Edit Displays the conversion scene group data tool in the

Edit Pane.

Precautions for Correct Use

The displayed line number changes according to the operation mode. In the Multi-line Random

rigger operation mode, the set number of lines are displayed. In the Non-stop Adjustment op-

eration mode, line 0 and 1 are displayed. For details on the operation mode, refer to Vision

System FH/FHV Series User's Manual (Cat. No. Z365).

2-4-5

Edit Pane

This pane is for displaying and editing the detailed data of all items.

The following screens are provided.

Screen Description

Reference

Page

Sensor connection screen This allows you to access the sensor information, the connec-

tio with the sensor, the main screen of each line, etc.

page 2 - 15

Monitor window This allows you to check the measurement results. page 2 - 16

Scene maintenance window This allows you to switch scenes or scene groups, and copy or

delete a scene and a scene group. It also allows you to per-

form test measurement and check the measurement results.

page 2 - 20

2 Basic Operations

2 - 13

FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)

2-4 Description of Screen Components

2-4-5 Edit Pane
