Menu Name Description
View Multiview Explorer Displays the Multiview Explorer.
Toolbox Displays the Toolbox.
Reset Window Layout Resets the window layout.
Insert Controller Inserts an NJ or NX project.
Displacement Sensor Inserts a ZW project.
Vision Sensor Inserts an FH or FHV project.
Tools Options Displays the Options menu.
Help Help Contents Displays V
ision System FH/FHV Series Operation Manual
Sysmac Studio (Cat. No. Z343).
Keyboard Mapping Reference Displays the shortcut key reference.
Online Registration Performs online registration.
About Sysmac Studio Displays the version of Sysmac Studio.
2-4-3
Toolbar
Button Name Description
Copy Copies the selected item.
Paste Pastes the copied item.
Delete Deletes the selected item.
Help Displays V
ision System FH/FHV Series Operation Manual
Sysmac Studio (Cat. No. Z343).
2-4-4
Multiview Explorer
This pane will be the access point for all data of the FH/FHV series.
You can right-click any data item that can be set and select an item from the menu (context menu).
You can also display various editing screens in the Edit Pane.
Multiview Explorer can be displayed or hidden by clicking the display/hide bar on the left side of the
window. Even when hidden, it can be displayed temporarily by placing the mouse pointer over the
display/hide bar. Moving the mouse pointer away from the bar returns the Multiview Explorer to the
hidden state.
Item list that make up the Multiview Explorer and the menu items displayed by right-clicking
Tree View Items Menu Item Description
Device Group Add - FH/FHV Adds a sensor to the project.
Rename Changes the device group name.
2 Basic Operations
2 - 11
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
2-4 Description of Screen Components
2
2-4-3 Toolbar
