9-2
Synchronization with the NJ/NX/NY-
series Controllers
For details on the synchronization to the NJ/NX/NY-series controller, refer to Sysmac Studio Version 1
Operation Manual (Cat. No. W504).
Consider the following limitations when synchronizing the project with the NJ/NX/NY-series controller
to which the FH/FHV vision sensor is connected.
l
Downloading ([Transfer to Controller])
• The setting data in FH/FHV vision sensor are not downloaded
• To download the setting data in FH/FHV vision sensor, establish an online connection for the vi-
sion sensor. Refer to 2-8 Precautions on Synchronization through an NJ/NX/NY-series Controller
on page 2 - 44.
• The global variables allocated to the FH/FHV vision sensor I/O ports in the I/O Map are down-
loaded.
l
Uploading ([Transfer to computer])
• The setting data in FH/FHV vision sensor are not uploaded.
• The FH/FHV vision sensor setting data are initialized after uploading. Be sure to establish an on-
line connection for FH/FHV vision sensor before the synchronization. Refer to 2-8 Precautions on
Synchronization through an NJ/NX/NY-series Controller on page 2 - 44.
• The global variables allocated to the FH/FHV vision sensor I/O ports in the I/O Map are down-
loaded.
9 Limitations
9 - 8
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
