Omron SYSMAC FH Series Operation Manual

6-4
Saving Measurement Results
If you wish to save measurement results or images, use the logging related processing units.
• Image logging
• Image conversion logging
• Data logging
• Result Output (Message)
Using these processing unites, allow to output the measurement results to the FH/FHV vision sensor
or the external memory,i.e. USB memory.
For details on the processing units, refer to Vision System FH/FHV Series Processing Item Function
Reference Manual (Cat. No. Z341).
To acquire the files output to the RAMDisk or the external memory, i.e. USB memory of the FH/FHV
vision sensor, use the file management tool.
For details, refer to 8-3 Using the File Save Tool on page 8 - 4.
6 Online Debugging
6 - 8
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
