Project Management
Sysmac Studio manages the configuration information of each of the controller, servo, and vision sen-
sor devices on a project basis.
Here, we describe the contents of the project data related to the FH/FHV Series and how the data is
managed.
Project data
Data related to the NJ/NX/NY-series Controller Data related to the FH/FHV sensor
Data related to Servo Drives Data related to other vision sensors
1-2-1
Project data
Eight FH/FHV vision sensor series devices can be registered to one project.
In the FH/FHV Series, the following types of data provided by Sysmac Studio are managed as project
data.
•
Scene group data (scene data)
• System data
• Tool data (communications command macros, security settings, and other data)
By using the Multi-line Random-trigger Mode, the FH sensor controller independently processes multi-
ple processing lines at the same time. In Multi-line Random Trigger mode, the above data is controlled
separately for each line. (It can not be used with the FHV series.)
Project data manages this data together as one batch. These data can also be exported and imported
individually as file data.
1 Overview
1 - 3
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
1-2 Project Management
1
1-2-1 Project data
To Next Page
