Sensor connection
Establish an online connection with the sensor.
(1) Connecting a sensor
For details, refer to S
ection 3 Connecting with a Vision Sensor on page 3 - 1.
Design
Create the processing flow.
(1) Creating flow
For details, refer to 2-6 Basic Operations of Flow Editing on page
2 - 35.
(2) Editing processing units
For details, refer to 4-2 Editing a Processing Unit on page 4 - 5.
Online debugging of sensor
Perform debugging using the actual device.
(1) Performing test measurement
Perform test measurement on sample work. Adjust the parameters if necessary
.
For details, refer to Section 6 Online Debugging on page 6 - 1.
