4-20 Workstation 5A Setup Guide - Fourth Edition
Installing and Operating the Workstation 5A
Operation
Using the Windows Embedded CE Screen Saver and Backlight Utility
The Workstation 5A with Windows Embedded CE 6.0 R3 includes a custom
enhanced Windows CE Screen Saver and Backlight Utility.
By default, after five minutes of inactivity, the screen saver engages and
displays a Workstation 5A logo. If the unit remains inactive for an additional
twenty minutes, the LCD backlights turn off. The operator LED remains solid
White. Touching the screen or swiping a mag stripe card restores the LCD
backlights. Instructions for modifying the default settings and using a custom
logo can be found below.
Procedure:
1. From the desktop, Touch Start -> Control Panel -> Screen Saver.
• The Screen Saver Properties window appears. An example of this screen,
with the default settings, is shown in Figure 4-14, below.
Figure 4-14: The Windows CE Screen Saver and Backlight Controls
Main Screen Saver
• To disable the screen saver, remove the check mark from the ‘Enable
Screen Saver’ box, touch [Apply] then [OK].
• To change the elapsed time before the screen saver engages, use the
‘Wait’ field up/down arrows to select the new value, touch [Apply],
then [OK].
• To change the screen saver from the ‘Float’ mode to the ‘Tile’ mode,
touch the ‘Tile’ check box, then [Apply] and [OK]. Touch the
[Preview] button to see an example of the screen saver.
