5-4 Workstation 5A Setup Guide - Fourth Edition
WS5A Diagnostics
Workstation 5A Diagnostics Utility
Workstation 5A Diagnostics Utility
Windows Embedded CE 6.0 based units use the WS5A Diagnostics Utility,
and POS Ready 2009 uses an updated version of the PCWS Diagnostics
Utility.
The Diagnostics Utility provides a great deal of information about the platform
hardware and software in addition to a set of comprehensive tests of the
hardware and supported peripherals.
Running the Windows CE Diagnostics Utility
For Windows Embedded CE 6.0 configurations, the utility is located in the
\DOC\Utilities folder.
1. From the Desktop, touch My Device, then touch ‘DOC’
2. Touch the Utilities Folder, then select ‘WS5ADiagUtility.’
System Information Screen
When the WS5A Diagnostics Utility starts, it displays the System Information
Screen, as shown below.
Figure 5-1: The WS5A System Information Screen (GR2.0)
The System Information screen the WS5A hardware and platform software
components in a central location. A brief description of each field and button
fol
lows.
