1-18 Workstation 5A Setup Guide - Fourth Edition
What is the WS5A?
General Specifications
General Specifications
The following table provides details about the Display, Network and I/O
capabilities of the Workstation 5A.
Specification Parameters
Processor and
Chipset
Intel Atom N450, Single Core, 1.6GHz and
Intel ICH8M I/O Controller Hub
Display 15” TFT LCD (1024x768) 262K Colors Max.
Touchscreen EloTouchSystems Five-wire resistive, 100
thousand points-per-inch resolution rated at a
screen life of over 35 million touches. Capacitive
option is available.
Backlight(s) Two CCFL backlights with three intensity settings
programmable through the API.
Real Time Clock 100-year calendar with alarm features and century
roll-over, includes 242 bytes of battery backed
CMOS RAM.
Memory 2 SO-DIMM Sockets - Max 2 GB DDR2 667
Mag Stripe Reader 3-Track ABA compatible, operates in MAGTEK
and Special modes.
Optional Customer Displays 240x64 STN graphics based LCD.
Protégé 7” TFT Color Customer Display System
USB Ports Ten USB 2.0 ports.
> Five internal
> Five external (Four USB type A, one optional
powered USB). External USB ports can be
disabled.
LAN Interface 10/100/1000 Ethernet - Modular RJ45
Serial Ports 1 DB9 RS232 Serial /w handshake
2 Modular RS232 Serial /w handshake
1 Modular IDN Serial (RS422 or RS232)
Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz.
Input Power 24W Typical
BTU/Hour 83 Typical
Storage Temperature -25°C (-13°F) to 80°C (176°F)
Workstation 5A Operating
Temperature
0°C (32°F) to 45°C (113°F), 90% relative humidity
max.
Weight 10.5 lbs. (4.7 kg) / Shipping weight 14.0 lbs. (6.35
kg)
