1-8 Workstation 5A Setup Guide - Fourth Edition
What is the WS5A?
The System
Workstation Mounting Options
All of the mounting options available for the Workstation 5 also apply to the
Workstation 5A.
The Workstation 5A Adjustable Stand
The Adjustable Stand converts the low profile WS5A into an adjustable
display design. The stand has a weighted base for stable operation, generous
cable area, printer power supply compartment and locking hinges to allow the
workstation to be positioned in the range of 25° and 70°.
Figure 1-5: The Workstation 5A Adjustable Stand
The rear of the stand includes a pair of knobs that secure the workstation to the
stand. The base includes a knock-out for a custom bracket that supports third
party peripherals.
