Workstation 5A Setup Guide - Fourth Edition 4-25
Installing and Operating the Workstation 5A
Operation
Calibrating The Touchscreen
Calibrating the touchscreen is the process of aligning the touchscreen glass
with the underlying video display.
When to Calibrate the Touchscreen
• When installing a new workstation.
• Any time the cursor does not follow the movement of your finger, or does
not reach the edges of the touchscreen.
• If the LCD panel or touchscreen glass have been replaced.
• After performing a workstation Personality Swap (Windows CE Only).
Tips for Calibrating the Touchscreen
• Perform the calibration procedure in the position (sitting or standing) that
the workstation is normally used.
• Face the Touchscreen directly. If the workstation is on a stand, adjust it to
the optimum viewing angle.
Windows Embedded CE 6.0
1. From the desktop, press Start -> Settings -> Control Panel and tap the
‘EloTouch icon. Touch or click the ‘Calibrate’ button to proceed.
• If you do not touch the screen within twenty seconds, the calibration
utility will shut down and retain the previous calibration values.
2. To begin, touch the center of the cross-hair that appear on the screen.
Continue to touch each target at the positions indicated - upper right, and
lower right.
• Make sure the cursor follows you finger at each corner of the screen.
Press [Accept] to compete the procedure and exit the utility.
POSReady 2009
Touch the desktop icon to start the touchscreen calibration.
To Next Page
