Server Upgrade Process
58 SPARC T5-4 Server Service Manual • July 2016
Processor modules are cold-service components that can be replaced only by qualified
service personnel. For the location of the processor modules, see “Front Panel
Components” on page 14.
Caution - These service procedures require that you handle components that are sensitive to
electrostatic discharge. This discharge can cause failure of server components.
This table contains the steps for upgrading the server to a fully-populated configuration. You
can also view an animated demonstration of the upgrade process at:
http://download.oracle.com/SPARC/T5-4-Server/SPARC_T5-4-Server-Upgrade.mp4
or:
http://download.oracle.com/SPARC/T5-4-Server/T5-4_Demo.html
Step Description Link
1 Remove the upgrade components from their packaging, and
place them on an antistatic mat.
2 Remove the covers from the new processor module. “Remove a Processor Module or Processor Filler
Module” on page 61
3 Remove all of the DIMM filler panels in the processor
module. The steps to remove the DIMM filler panels are the
same as the steps for removing DIMMs.
“Remove a DIMM or DIMM Filler Panel” on page 77
4 Verify that you have the correct DIMMs for your server. All of
the DIMMs must be either 16 or 32 GB, and they must match
the size and capacity of the DIMMs already installed in the
server.
“DIMM Population Rules” on page 69
5 Install the DIMMs. “Install a DIMM” on page 79
6 Check the server for faults. If any fault is present, you must
correct the fault and clear it from the server before you can
continue with the upgrade.
“Check for Faults” on page 38
7 Shut down the server. “Removing Power From the Server” on page 51
8 Remove the processor filler module from Slot 1. “Remove a Processor Module or Processor Filler
Module” on page 61
9 Install the new processor module in Slot 1. “Install a Processor Module or Processor Filler
Module” on page 64
10 Return the server to operation. “Returning the Server to Operation” on page 191
11 Verify the installation. If any fault is present, you must correct
the fault and clear it from the server.
“Verify the Processor Module” on page 67
12 Review the root complex changes. “PCIe Root Complex Connections (Dual-Processor
Configurations)” on page 153
13 Review the PCIe card load balancing changes. Even though
the load balancing guidelines change with the u;pgrade, you
do not need to move any existing PCIe cards.
“PCIe Card Installation Order” on page 155
