DIMM Addresses
70 SPARC T5-4 Server Service Manual • July 2016
■
512 Gbytes (all 16-Gbyte DIMMs in one processor module)
■
1024 Gbytes (all 16-Gbyte DIMMs in two processor modules)
■
1024 Gbytes (all 32-Gbyte DIMMs in one processor module)
■
2048 Gbytes (all 32-Gbyte DIMMs in two processor modules)
Note - If you are adding a second processor module to the server, you must install DIMMs
of the same type and capacity that are already in the existing processor modules. See “Server
Upgrade Process” on page 57.
Related Information
■
“DIMM Addresses” on page 70
■
“DIMM Rank Classification” on page 72
■
“Remove a DIMM or DIMM Filler Panel” on page 77
■
“Install a DIMM” on page 79
■
“Verify a DIMM” on page 82
DIMM Addresses
The following figure illustrates the DIMM addresses on a processor module:
