Servicing the Service Processor Card
These topics describe service procedures for the service processor in the server.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause failure of server components.
Steps Description Links
1. Determine if the service processor card is faulty. “Determine if the Service Processor Card Is
Faulty” on page 115
2. Remove the main module. “Remove the Main Module” on page 99
3. Replace the service processor card. ■ “Remove the Service Processor
Card” on page 116
■ “Install the Service Processor
Card” on page 118
4. Install the main module. “Install the Main Module” on page 102
5. Verify the replacement service processor card. “Verify the Service Processor Card” on page 120
Determine if the Service Processor Card Is Faulty
The following LEDs are illuminated when a SP fault is detected:
■
System Service Required LEDs on the front panel and rear I/O module
■
Server SP LED on the main module or rear I/O module
1.
Determine if the System Service Required LEDs are illuminated on the front
panel or the rear I/O module.
See “Interpreting LEDs” on page 28.
2.
Check the SP LED on the main module or the rear I/O module to determine if the
service processor card needs to be replaced.
See “Main Module LEDs” on page 98 or “Rear Panel Controls and LEDs” on page 31. The SP
LED is illuminated amber if the service processor card needs to be replaced.
3.
Remove the faulty service processor card.
See “Remove the Service Processor Card” on page 116.
