Install a Storage Backplane
Servicing the Storage Backplanes 111
9.
Push the top edge of the storage backplane slightly toward the rear of the main
module, then lift the storage backplane up and remove it from the main module.
Related Information
■
“Install a Storage Backplane” on page 111
Install a Storage Backplane
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause failure of server components.
1.
Take the necessary ESD precautions.
See “Prevent ESD Damage” on page 54.
2.
Position the storage backplane in the main module.
