Install the Rear Chassis Subassembly
Servicing the Rear Chassis Subassembly 187
Install the Rear Chassis Subassembly
1.
Slide the rear chassis subassembly into the server.
2.
Using a Phillips screwdriver, tighten the four green screws to secure the rear
chassis subassembly in the server.
Tighten the screws in the following order:
a.
Lower right screw.
b.
Upper left screw.
c.
Upper right screw.
d.
Lower left screw.
3.
Remove the connector covers from the replacement rear chassis subassembly.
4.
Install the following components back into the rear of the server:
■
All five fan modules – see “Install a Fan Module” on page 149.
