Remove a PCIe Card Carrier
158 SPARC T5-4 Server Service Manual • July 2016
See “Interpreting LEDs” on page 28.
2.
Determine if the PCIe Fault LED is illuminated on the front panel.
See “Front Panel Controls and LEDs” on page 29.
3.
From the rear of the server, find the PCIe carrier that has an amber Service
Required LED lit.
4.
Remove the faulty PCIe card.
See “Remove a PCIe Card Carrier” on page 158.
Related Information
■
“Understanding PCIe Root Complex Connections” on page 151
■
“Remove a PCIe Card” on page 161
■
“Install a PCIe Card” on page 163
■
“Verify the PCIe Card” on page 170
Remove a PCIe Card Carrier
The SPARC T5-4 server supports single-wide and double-wide card carriers. The removal steps
are the same for both carrier types. This topic includes illustrations only for the single-wide
carrier.
Note - If you are installing a PCIe card that requires a double-wide carrier, you must remove
two adjacent PCIe card carriers.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause failure of server components.
Note - Removing PCIe card carriers while the server is at the OpenBoot prompt is not
supported. The server must be either powered off, or booted into the Oracle Solaris OS.
1.
Take the necessary ESD precautions.
See “Prevent ESD Damage” on page 54
2.
Locate the PCIe card carrier at the rear of the server.
See “Determine Which PCIe Card Is Faulty” on page 157 to locate a faulty PCIe card.
3.
Determine if you are removing a PCIe card carrier from a running server.
