Processor Module Components

18 SPARC T5-4 Server Service Manual • July 2016

■

“Component Service Task Reference” on page 20

Processor Module Components

These components are accessible within the processor module when you remove the processor

module from the front of the server.

No. Description Link

1 DIMMs “Servicing DIMMs” on page 69

Related Information

■

“Servicing Processor Modules” on page 57

■

“Servicing DIMMs” on page 69
