Determine Which Hard Drive Is Faulty
90 SPARC T5-4 Server Service Manual • July 2016
■
“Install a Hard Drive” on page 93
■
“Verify the Hard Drive” on page 94
Determine Which Hard Drive Is Faulty
The following LEDs are lit when a hard drive fault is detected:
■
System Service Required LEDs on the front panel and rear I/O module
■
Service Required LED on the faulty drive
1.
Determine if the System Service Required LEDs are lit on the front panel or the
rear I/O module.
See “Interpreting LEDs” on page 28.
2.
From the front of the server, check the drive LEDs to identify which drive needs
to be replaced.
See “Hard Drive LEDs” on page 89. The amber Service Required LED is lit on the drive
that needs to be replaced.
3.
Remove the faulty drive.
See “Remove a Hard Drive” on page 90.
Related Information
■
“Hard Drive Locations” on page 87
■
“Hard Drive Hot-Service Capabilities” on page 88
■
“Hard Drive LEDs” on page 89
■
“Remove a Hard Drive” on page 90
■
“Install a Hard Drive” on page 93
■
“Verify the Hard Drive” on page 94
Remove a Hard Drive
Hard drives are hot-service components that can be replaced by customers. For the location of
the hard drives, see “Hard Drive Locations” on page 87.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. This discharge can cause failure of server components.
