Remove the Rear Chassis Subassembly

184 SPARC T5-4 Server Service Manual • July 2016

No. Description

1 Server chassis

2 Midplane subassembly

3 Rear chassis subassembly chassis

Related Information

■

“Remove the Rear Chassis Subassembly” on page 184

■

“Install the Rear Chassis Subassembly” on page 187

Remove the Rear Chassis Subassembly

Verify that the rear chassis subassembly needs to be replaced.

Use the server software to determine if the rear chassis subassembly needs to be replaced. See

“Detecting and Managing Faults” on page 23 for more information.
